NATPure System
Intented Use
CWNP-32 (Figure 1-1) utilizes magnetic bead separation technology, where the movement of magnetic rods and magnetic sleeves enables the collection, release, transfer, and incubation of magnetic beads, thereby completing the entire nucleic acid extraction process.
It is used for the extraction and purification of nucleic acids from clinical samples. CWNP-32 is intended for use by specially trained personnel for professional use. Specifically, it is designed for the fully automated transfer and processing of magnetic beads in deep-well plates. It is recommended to adhere to Good Laboratory Practice (GLP) to ensure the reliability of the analysis.
Order Information
| Cat. no. | Product Name | Package | Note | |
| CW11022Q-32 | NATPure System | 1 unit | 32-channel，model: CWNP32 |
Performance Parameters
| Table 6-2 Performance Parameters | |
| Volume | 20 µl- 1000µl |
| Throughput | 1-32 |
| Bead Recovery Efficiency | ≥99% |
| Magnetic Rod | 32 |
| Number of Deep Well Plates | 2 |
| Deep Well Plate Type (Disposable) | 96-well deep well plate, 6-tube reagent strip (20–1000 µl*) |
| Magnetic Sleeve (Polypropylene-Disposable) | 2 units per 96-well deep well plate |
| Heating Temperature | |
| -Plate row module | From 10°C to 99°C, instrument at ambient temperature |
| -Elution module | From 10°C to 99°C, instrument at ambient temperature |
| Heating module accuracy | ±1°C, up to 75°C, instrument at ambient temperature |
| Display screen | 10" LCD, 480×800 pixel color display |
Recommended Supporting Reagents
| REF | Product Name | Certification | Package Size |
| CW05021N | Cowingene DNA/RNA Extraction kit | CE | Pre-packaged, single serving -universal sample types |
| CW05021M | Cowingene DNA/RNA Extraction kit | CE | Pre-packaged, multi-serving - universal universal sample types |
| CW05021N-HG | Cowingene DNA/RNA Extraction kit | CE | Pre-packaged, single-serving - human genome |
| CW05021M-HG | Cowingene DNA/RNA Extraction kit | CE | Pre-packaged, multi-serving - human genome |
