NATPure System-Mini-Automatic Nucleic Acid Extractor

REF:CW11022Q-16

CONTACT NOW

NATPure System

Intented Use

CWNP-16 (Figure 1-1) utilizes magnetic bead separation technology, where the movement of magnetic rods and magnetic sleeves enables the collection, release, transfer, and incubation of magnetic beads, thereby completing the entire nucleic acid extraction process.
It is used for the extraction and purification of nucleic acids from clinical samples. CWNP-16 is intended for use by specially trained personnel for professional use. Specifically, it is designed for the fully automated transfer and processing of magnetic beads in deep-well plates. It is recommended to adhere to Good Laboratory Practice (GLP) to ensure the reliability of the analysis.

Order Information

Cat. no.	Product Name	Package	Note
CW11022Q-16	NATPure System	1 unit	16-channel，model: CWNP16

Performance Parameters

Table 6-2 Performance Parameters
Volume	20 µl- 1000µl
Throughput	1-16
Bead Recovery Efficiency	≥99.5%
Magnetic Rod	16
Number of Deep Well Plates	1
Deep Well Plate Type (Disposable)	96-well deep well plate, 6-tube reagent strip (20–1000 µl*)
Magnetic Sleeve (Polypropylene-Disposable)	2 units per 96-well deep well plate
Heating Temperature
-Plate row module	From 10°C to 99°C, instrument at ambient temperature
-Elution module	From 10°C to 99°C, instrument at ambient temperature
Heating module accuracy	±1°C, up to 75°C, instrument at ambient temperature
Display screen	7-inch color screen

Recommended Supporting Reagents

REF	Product Name	Certification	Package Size
CW05021N	Cowingene DNA/RNA Extraction kit	CE	Pre-packaged, single serving -universal sample types
CW05021M	Cowingene DNA/RNA Extraction kit	CE	Pre-packaged, multi-serving - universal universal sample types
CW05021N-HG	Cowingene DNA/RNA Extraction kit	CE	Pre-packaged, single-serving - human genome
CW05021M-HG	Cowingene DNA/RNA Extraction kit	CE	Pre-packaged, multi-serving - human genome
